FEATURES
TECHNICAL DATA
| Code | Power | LED | Dim | Input | CCT | Lumen | CRI | Beam Angle |
| DL-CS20-104D3 |
4W | SMD2835 |
Yes |
220-240V~50/60Hz |
3000/4000/6500K |
400lm |
>80Ra |
110° |
| DL-CS23-104D3 | 5W | SMD2835 |
Yes |
220-240V~50/60Hz |
3000/4000/6500K |
550lm |
>80Ra |
110° |
| DL-CS30-108D3 |
8W | SMD2835 |
Yes |
220-240V~50/60Hz |
3000/4000/6500K |
890lm |
>80Ra |
110° |
| DL-CS40-110D3 |
10W | SMD2835 |
Yes |
220-240V~50/60Hz |
3000/4000/6500K |
1120lm |
>80Ra |
110° |
CONSTRUCTION
| Code | Driver |
Body Material | Trim Color | Dimension | Weight | Cutout | IP Rating |
| DL-CS20-104D3 |
DOB |
Iron+PP+PC | White/Black/Nickel |
D79*29mm |
55-68mm |
IP65 |
|
| DL-CS23-104D3 | DOB |
Iron+PP+PC | White/Black/Nickel | D89*28mm |
68-75mm |
IP65 | |
| DL-CS30-108D3 |
DOB |
Iron+PP+PC | White/Black/Nickel | D112*28mm |
90-100mm |
IP65 | |
| DL-CS40-110D3 |
DOB |
Iron+PP+PC | White/Black/Nickel | D147*28mm |
125-135mm |
IP65 |
PACKAGING INFORMATION
| Code | Unit/Inner Box | Inner Box Dimensions (L*W*H) |
Inner Box G.W. | Unit/Masterbox | Masterbox Size (L*W*H) |
Masterbox G.W. | Masterbox Volume |
| DL-CS20-104D3 |
|||||||
| DL-CS23-104D3 | |||||||
| DL-CS30-108D3 |
|||||||
| DL-CS40-110D3 |
